Characteristic

A. Using a reliable magnetic drive knob for local operation, it eliminates the traditional knob design or waterproof rubber buttons. This ensures the waterproof performance and durability of the device, making it suitable for outdoor applications.
B. The multifunctional display window provides rich information, allowing users to easily access basic settings parameters, operating status, and fault alarms.
C. Equipped with three-phase power supply, with automatic phase sequence detection and correction function. Installation does not require attention to phase sequence to prevent equipment damage due to incorrect installation. Including phase loss protection to ensure operational safety.
D. Equipped with comprehensive fault detection functions such as stall and oscillation detection. After detecting a fault, the device stops running to protect itself and the system, while displaying fault information on the screen. Includes 4 built-in passive contacts for outputting signals: valve fully open, valve fully closed, general fault, and control mode (local/remote).
E. Provide multiple on-site configurable operating modes: configurable forward/reverse action modes, as well as configurable actions in the event of control signal loss (fully open, stop, or fully close).
F. Instantaneous reverse protection: For example, if a close command is received during an open operation, the device will first stop and then delay for a preset time before executing the close action, thereby reducing mechanical shock.
G. The hybrid design allows for the switching of control modes (automatic/manual) through a single digital signal, facilitating remote automatic or manual control.
